Highway Flat

Maximum strength/weight ratio and maximum flexibility without deterioration.

Trailer Overview

Our Highway Flatbed trailers boast exceptional durability and are lightweight. With a structure made from 100 KSI steel, you get maximum strength/weight ratio and maximum flexibility without deterioration.

Models / Specs / Options

48HF2X, 48HF3X

Overall length of 48 feet
Overall width of 102 inches
Floor of 1 ⅛ inch shiplapped apitong/keruing inside the main beam, 1 ⅛ shiplapped softwood outside the main beams
Two or three axles of 25,000 lb capacity with ¾ inch wall
Ridewell RAR Air Ride 240 or 260 O/S 25,000 lb suspension, 15 inch ride height - includes air gauge and dump valve
Preparation for finish by steel shot blast, commercial/industrial topcoat, and oven baked
Standard colour is black

48HF4X

Overall length of 48 feet
Overall width of 102 inches
Floor of 1 ⅛ inch shiplapped apitong/keruing inside the main beam, 1 ⅛ inch shiplapped softwood outside the main beams
Three axles of 25,000 lb capacity with ¾ inch wall and one fixed liftable self steer axle with Reverse-O-Matic
Ridewell RAR Air Ride 260 O/S 25,000 lb suspension, 15 inch ride height - includes air gauge and dump valve
Preparation for finish by steel shot blast, commercial/industrial topcoat, and oven baked
Standard colour is black

50HF5X

Overall length of 50 feet
Overall width of 102 inches
Floor of 1 ⅛ inch shiplapped apitong/keruing inside the Main Beam, 1 ⅛ inch shiplapped softwood outside main beams
Five axles of 25,000 lb capacity with ¾ inch wall
Ridewell RAR Air Ride 260 O/S 25,000 lb suspension, 15 inch ride height - includes air gauge and dump valve
Preparation for finish by steel shot blast, commercial/industrial topcoat, and oven baked
Standard colour is black

53HF3X, 53HF4X

Overall length of 53 feet
Overall width of 102 inches
Floor of 1 ⅛ inch shiplapped apitong/keruing inside the Main Beam, 1 ⅛ inch shiplapped softwood outside main beams
Three or four axles of 25,000 lb capacity with ¾ inch wall and one fixed liftable Self-Steer with Reverse-O-matic for the four axle
Ridewell RAR Air Ride 260 O/S 25,000 lb suspension, 15 inch ride height - includes air gauge and dump valve
Preparation for finish by steel shot blast, commercial/industrial topcoat, and oven baked
Standard colour is black
