Trailer Overview

This log model services the forestry industry close to home.  Specifically designed for Eastern logging, our fabricated stakes, formed pockets (no weld, low stress) and floating cross members allow for torsional twisting without cracking of main frame.  Fitted with LED lights, HD front & rear bunks and full-length floor weld, this rugged logger flatbed trailer is a great option for those on the east coast.

Models / Specs / Options

46LD3X4T NS V2016

  • Overall length of 46 feet, 11 inches
  • Overall width of 108 inches
  • Floor of ⅛ inch deck plate over the deck with the loader area left open
  • Three axles of 25,000 lb capacity with 77.5 inch track and ¾ inch wall
  • Two Ridewell Air Ride suspensions of O/S 30,000 lbs, and one of U/S 30,000 lbs with a 15 inch ride height, c/w check chains and full manual dump
  • Preparation for finish by steel shot blast, commercial/industrial topcoat, and oven baked
  • Standard colour is black with light grey stakes

46LF3X4T NS V2017

  • Overall length of 46 feet
  • Overall width of 108 inches
  • Floor of ⅛ inch deck plate over the fifth wheel and between the main beams, over the suspension area is welded full length with the exception of the loader area
  • Ridewell Air Ride RAR 240 O/S 30,000 lbs suspension, with 15 inch ride, c/w check chains and full manual dump
  • Preparation for finish by steel shot blast, commercial/industrial topcoat, and oven baked
  • Standard colour is black with light grey stakes

48LD4X4T NB V2017

  • Overall length of 48 feet
  • Overall width of 102 inches
  • Floor of ⅛ inch deck plate between the main beams, welded full length
  • Three axles of 25,000 lb capacity with 77.5 inch track and ¾ inch wall, and one BWS fixed liftable self steer axle with Reverse-Amatic and control box
  • Ridewell Air Ride RAR 240 O/S 30,000 lbs suspension, with 15 inch ride, c/w check chains and full manual dump
  • Preparation for finish by steel shot blast, commercial/industrial topcoat, and oven baked
  • Standard colour is black with light grey stakes

51LD4X5T NB V2016

  • Overall width of 51 feet, 7 inches
  • Overall width of 102 inches
  • Floor of ⅛ inch deck plate over the deck, left open over loader area
  • Three axles of 25,000 lb capacity with 77.5 inch track and ¾ inch wall, and one BWS fixed liftable self steer axle with Reverse-Amatic and control box
  • Ridewell Air Ride RAR 240 O/S 30,000 lbs suspension, with 15 inch ride, c/w check chains and full manual dump
  • Preparation for finish by steel shot blast, commercial/industrial topcoat, and oven baked
  • Standard colour is black with light grey stakes

48LF3X5T NB V2016, 48LF4X5T NB V2016

  • Overall length of 48 feet, 8 inches
  • Overall width of 102 inches
  • Floor of ⅛ inch deck plate between the main beams, welded full length
  • Three axles of 25,000 lb capacity with 77.5 inch track and ¾ inch wall, and one BWS fixed liftable self steer axle with Reverse-O-Matic and control box on the 48LF4X5T NB V2016 model
  • Ridewell Air Ride RAR 240 O/S 30,000 lbs suspension, with 15 inch ride, c/w check chains and full manual dump
  • Preparation for finish by steel shot blast, commercial/industrial topcoat, and oven baked
  • Standard colour is black with light grey stakes

51LF3X5T NB V2016, 51LF4X5T NB V2016

  • Overall length of 50 feet, 7 inches
  • Overall width of 102 inches
  • Floor of ⅛ inch deck plate between the main beams, welded full length
  • Three axles of 25,000 lb capacity with 77.5 inch track and ¾ inch wall, and one BWS fixed liftable self-steer axle with Reverse-O-Matic and control box on the 51LF4X5T NB V2016 model
  • Ridewell Air Ride RAR 240 O/S 30,000 lbs suspension, with 15 inch ride, c/w check chains and full manual dump
  • Preparation for finish by steel shot blast, commercial/industrial topcoat, and oven baked
  • Standard colour is black with light grey stakes
